The G800 is a vehicle tracking device that plugs into a vehicle's OBDII port. Its compact design allows easy installation. Its internal OBD reader can obtain information from the vehicle's onboard computer and relay it over GPRS networks. Its built-in GPS receiver has superior sensitivity and fast time to first fix. Its 4G LTE GPRS/GSM subsystem supports TDD LTE& FDD LTE frequency allowing the G800's location to be monitored in real time or periodically tracked by a backend server and mobile devices. Its built-in 3-axis accelerometer allows motion detection. Meanwhile, it supports 4G WIFI hotspots so passengers can access high-speed data. Maximum support 10 user access at the same time.
Vehicle Tracking Device
Technician parameter
Name | Parameter |
Gift Box Dimension | 120*120*50mm |
Tracker Color | White |
Working voltage | 8V – 28V DC, suitable for 12V vehicle. |
Working current | 120mA?12V/DC?,10mA in sleeping mode. Hotspot mode: 200mA-300mA |
Back-up battery | N/A, |
Tracker size | 50*60*24 mm |
Working temperature | -25? -- 75? |
Moisture | 5% -- 95%?Non-water vapor condensation state? |
4G LTE Frequency | QUECTEL EC25 LTE Module.(or EC20 ) FDD LTE: B1/B3/B8 (2100Mhz/1800Mhz/900Mhz) TDD LTE: B38/B39/B40 (2600Mhz/1900Mhz/2300Mhz) TDSCDMA: B34/B39 UMTS: B1/B8 GSM: 900/1800MHz |
GPS Module | SKYLAB SKG09BL |
GPS Sensitivity | -159Db |
GPS Frequency | 1575.42 MHz |
Receiving panel structure | GPS module 66-channel |
Wifi Module | QUECTEL FC20, support maximum 10user online together ; |
Locating accuracy | < 5m ?95?? |
Cold start time | < 45s(on average? |
Heat start time | < 2 s (on average? |
LED indicator light | usage of green / red dual-color LED indicator light shows the GPS / GSM status |
LTE Chipset | QUECTEL LTE (Industry M2M GSM modem) |
Supported OBD protocol: | ISO 9141-2 ISO 14230-1 ISO 14230-2 ISO 15765-2 ISO 15765-4 |
G-sensor: | ±2/4/8G |
Parameter reading from Vehicle ECU?
Mileage, Engine RPM, Ignition, Water Temperature...
Support firmware updated by air (OTA), mini-USB port for data reading and configuration;
support GPRS blank area data record and re-upload
Definition of 16 PIN:
1. GM company CAN-BUS
2. ISO 11519-4 (Bus+) (SAE J1850)
3. Chrysler CCD-BUS H line
4. Chassis GND
5. Logic signal GND
6. ISO 15765-4; CAN-BUS High-speed diagnostic cable (CAN H wire),250/500 kbps/s
7. ISO 9141-2/KWP2000 protocol K line
8. Vehicle manufacturer reserved
9. Vehicle manufacturer reserved
10. ISO 11519-4 (Bus-)(SAE J1850)
11. Chrysler CCD-BUS L line
12. Vehicle manufacturer reserved
13. Vehicle manufacturer reserved
14. ISO 15765-4; CAN-BUS High-speed diagnostic cable (CAN L wire)
15. ISO L line
16. Battery power + wire LED light Description
There are two LED lights on the PCBA board, one
LED Light | Indication | |
Flashing quickly | Flashing slowly | |
Blue | Ignition On, reading vehicle ECU data | Ignition Off, OR not support this vehicle. |
RED | GPRS data linking correctly | GPRS data link fail |
Green | GPS located | GPS not located |
